Polyamide 6

3D Printer Filament

Edition Number :
20181031
Edition Date :
October 31, 2018

Clariant polyamide 6 3D printer filament is made of a good flowing Polyamide 6 that results in high performance 3D printed parts. Clariant Hostanox® P-EPQ® and Nylostab® S-EED® are added via a Renol® masterbatch to improve resistance to thermo-oxidative degradation and minimize yellowing due to ultraviolet radiation.

Print Data Sheet
David McCann

David McCann

Contact Person

Request to Clariant

close

Please enter your contact information so we are able to process your request. Thank you for your interest.

Your Name



Your Email

Your Company

Country

Message

Send Message

  • Benefits

    Benefits

    General properties
    • Semi-crystalline thermoplastic
    • High impact strength
    • High stiffness
    • Outstanding wear resistance
    • Good coefficient of friction
    • Very good temperature resistance

    Optimized benefits
    • Reduced thermo-oxidative degradation
    • Increased process stability at high processing temperatures
    • Improved long term heat and stability to ultraviolet and visible light

    Applications*
    • Mechanical and technical application parts that require toughness and durability
    • Models
    • Prototypes

    *Subject to detailed product specifications.

  • Safety & MSDS

    Safety & MSDS



    Contact Us
    Please contact us for safety and regulatory details or the Material Safety Data Sheet (MSDS).
  • Printing Parameters

    Printing Parameters

    • Print Temperature = 250-280°C
    • Print Speed = 20-50 mm/s
    • Bed Adhesion = directly on glass, polyimide film or a PEI surface all with a thin coating of polyvinylpyrrolidone (PVP) based glue
    • Bed Temperature = ideally heated up to 70°C
    • Fan Settings = medium to high

    Note: parameters are dependent on printer used; Clariant tests were performed on an Ultimaker 3 extended and a 3ntr A4 V2 printer.

  • Typical Property Values

    Typical Property Values

    Property Typical ValuesUnitsTest MethodTest Specimen
      white blackcoloranatural
    MECHANICAL PROPERTIES
    Tensile stress at yield, 50 mm/min7678 75MPaISO 527Injection molded
    Tensile elongation at break, 50 mm/min3020 19%ISO 527Injection molded
    Flexural modulus23202480 2490MPaISO 178Injection molded
    Flexural strength93101 96MPaISO 178Injection molded
    Izod impact strength notched2.94.0 2.8MPaISO 180Injection molded
    Charpy impact strength notched   5330J/m2ISO 180Injection molded
    THERMAL PROPERTIES
    Melting point   221°CISO 11357, DSCb
    Glass transition temperature   n/a°CISO 11357, DSCb
    Heat deflection temperature at 1.8 MPa (A)5758 55°CISO 75Injection molded
    Heat deflection temperature at 0.45 MPa (B)146165 175°CISO 75Injection molded
    Heat deflection temperature at 0.45 MPa (B)
    		°CISO 753D printed XY / flat
    GENERAL PROPERTIES
    Density11431141 1130kg/m3ISO 1183
    a. Organic based color. b. DSC = Differential Scanning Calorimetry at 10°C/minute.
    Note: results are generated according to the valid testing standards indicated above and the standard operating procedures used by the testing facilities.
  • Available Colors

    Available Colors

    Standard Color Range
    • White
    • Black
    • Grey

    ColorWorks® ColorForward® consumer color directions 2019
    • MADE IN HUMAN - Protect the core (red)
  • Packaging and Handling

    Packaging and Handling

    Delivery form
    1.75 mm and 2.85 mm diameter 3D printer filament.

    Packaging
    1 kg and 5 kg spools of 3D printer filament.Custom sizes are available upon request.

    Storage
    Ideally store the 3D printer filament in a cool, dry place at temperatures between 5 to 25°C in a sealed container with the provided Clariant Desi Pak® desiccant bag. If the 3D printer filament has been exposed to moisture, please dry at 80°C for at least 4 hours with a vacuum or desiccant drying system if possible. Minimum shelf life is 1 year from the date of shipping when properly stored.
