二塩化エチレンとテレフタル酸触媒

Ethylene_Derivatives_Picture

Production of ethylene dichloride (EDC) by oxychlorination

オキシ塩素化による二塩化エチレン (EDC) の生産

PVC(ポリ塩化ビニル)は最も広く製造されている合成プラスチックポリマーの一つです。PVCは、塩化ビニルモノマー(VCM)をポリマー化することにより製造されます。二塩化エチレン(EDC)はこのプロセスの基礎を成します。これは、オキシ塩素化プロセスを通して流動床反応器内でエチレンから製造されます。

クラリアントは1983年以来、このオキシ塩素化プロセス用の触媒を提供しており、その性能の改善に継続して取り組んできました。現在、40を超えるプラントがクラリアントの OxyMax 流動床触媒シリーズを用いて操業しています。

OxyMax™は、空気供給、酸素供給の流動層プロセスに最適化されています。また、ガス成分、温度、プラントの能力などが異なる幅広い運転条件下で機能します。OxyMax™触媒は、運用中の高い活性と安定性に加えて、EDCに対する高い選択性を提供します。

  • OxyMax A: すべての標準流動床アプリケーションに適します
  • OxyMax B: 中温から高温向け (225~240°C)
  • OxyMax V: 流動層リアクターで最大パフォーマンスを発揮
  • OxyMax M:  三井ケミカル テクノロジを利用した流動層リアクター向け
  • OxyMax MW:  OxyChem’s Catoxidテクノロジを利用した反応器用の補給触媒です
  • OxyMax S: 活性を高め、微粒子ロスの修復を図るように開発された補給触媒で、高い微粒子ロスが発生した場合に推奨されます

テレフタル酸の精製(PTA)

テレフタル酸は、プラスチックボトルや衣服に用いられるポリエステルPETの前駆体です。粗テレフタル酸は、パラキシレンの接触空気酸化により製造されます。この工程で、不要な副産物が生成されます。その中で特に、4-カルボキシベンズアルデヒド(4-CBA)は着色化合物であるため、除去が必要になります。

そのために、クラリアントの H2MAX 触媒を用いて、固定床反応器内で粗テレフタル酸を精製します。着色副産物は無色の水溶性物質へと水素化されます。最終的には、精製テレフタル酸(PTA)は通常、4-CBAの20ppm(百万分率)未満になります。

H2MAX 触媒は、貴金属のパラジウムを含有します。クラリアントは、触媒活性の長期的安定性の維持を確保する特殊な製造技術を用いて、触媒を製造します。貴金属触媒については、運用中に有価金属を最大限に保持することが重要です。H2MAX は、その他の最先端の触媒に比べ、より多くのパラジウムをその寿命期間にわたって保持します。したがって、パラジウムの購入量が減り、お客様のコスト節減につながります。

  • H2Max 50: パラジウム保持が強化された標準シリーズのPTA触媒
  • H2Max HD: 支持構造上の貴金属の分散および分配(特許取得済み)により、パラジウム保持がさらに向上しています

Purification of terephthalic acid (PTA)

Terephthalic acid is a precursor to the polyester PET, used to make plastic bottles and clothing. Crude terephthalic acid is produced by catalytic air oxidation of p-xylene. During this process, unwanted by-products are formed. One in particular, 4-carboxybenzaldehyde (4-CBA), needs to be removed, as it is a colored compound.

Therefore, the crude terephthalic acid is purified in a fixed-bed reactor using Clariant’s H2MAX catalyst: the colored by-products are hydrogenated to uncolored and water-soluble substances. In the end, the purified terephthalic acid (PTA) has typically less than 20 parts-per-million (ppm) of 4-CBA.

H2MAX catalysts contain palladium, a precious metal. Clariant produces the catalysts with a unique production technology that assures their activity remain stable for a long time. For precious metal catalysts, it is important that they preserve as much as possible of the valuable metal during operation. H2MAX retains more palladium during its lifetime than other state-of-the-art catalysts. This means that customers save money, as they need to buy less palladium.

  • H2Max 50: standard grade PTA catalyst with strong palladium retention
  • H2Max HD: providing even higher palladium retention thanks to patented dispersion and distribution of the precious metal on the support structure
